Mitutoyo Digimatic Vernier Calliper

Backed with huge industry experience and market understanding, we are involved in providing a wide variety of ABS Digimatic Caliperfor our valued patrons.

A new series of cost-effective standard Digimatic caliper born of Mitutoyo’s ground-breaking encoder technologies developed over the last 30 years.

Now equipped with the same AOS (Advanced Onsite Encoder) induction type encoder used in top-of-the-line ABS coolant-proof calipers.

Features:

• A battery life of approximately 3.5 years has been achieved under normal use through the adoption of Mitutoyo’s ABSOLUTE scale.
• The slider configuration features an ergonomic, thumb-friendly shape.
• Step-measurement capable.
• Carbide-tipped jaw models are ideally suited to the measurement of rough machined workpieces, castings, grindstones, etc.
• The data output function allows integration into statistical process control and measurement systems.

Functions:

• ABS (absolute) measurement function: Enables absolute-mode measurement to be started without any zero-setting after switch-on. The absolute origin position can be set, or reset, with the ORIGIN switch at any time.

• INC (incremental) measurement function: Enables the display value to be set to zero, temporarily, at the current slider position to enable easy incremental-mode measurement.

• Low battery alarm: Indicates (with a ‘B’ symbol in the display) that the battery needs replacing. This allows timely battery replacement before the caliper becomes unusable.

• External output function: Allows measurement data to be exported using the optional data cable.

• Hold function: Allows a display value to be held using the optional Data Hold unit. (This function cannot be used along with the external output function).
